EN
8
6 - General Oven Information
Before using your oven for the first time remove all packing
and foreign materials from the oven(s). Any material of this
sort left inside may melt or burn when the appliance is used.
Error codes
This code appears in the event of the electronic control
indicating a fault. When the error appears, the current
function is blocked. If the type of error is related to a safety
function, the oven becomes unusable and every time a start
attempt is made, the same error appears (in which case
call in the after-sales service), while if the error relates to a
minor fault, after being restarted the oven can be used for the
functions that do not involve the faulty part (e.g., a heating
element).
Beeps
Confirms that the command has been received after a key
has been pressed.
It also indicates that a time function has been completed (e.g.
Timer or Timed Cooking). During the execution of a recipe,
an acoustic signal warns the user that the oven is waiting for
operation by the user (e.g., insert the dish or turn it over).
Beeps also signal an oven fault.
Door Lock
It’s displayed steadily when the door is locked. The symbol
flashes when the latch is moving in order to lock or unlock the
door. Do not attempt to open the door at this time. Door can
be opened when the symbol no longer appears. A padlock
appears when the door has been locked automatically due
to self-clean mode.
Power Failure
After the power returns to the oven, the door lock mechanism
perform a test run then the clock time and date are displayed
Default Settings
The cooking modes automatically select a suitable temperature
when the cooking mode is selected, these can be changed
when a different one is needed.
F Failure Number Codes
These codes are displayed when the electronic control detects
a problem in the oven or in the electronics.
The error code is recorded in the Error Log in the Setup menu.
This error can be communicated to the service technician so
he/she can understand the possible cause of the problem in
advance.
Locking the keyboard
Hold the key for 3 seconds. Commands are now locked and a
“Key icon” will be displayed.
Repeat the same operation for 3 seconds to unlock the keyboard.
NOTE: The power off operation is always available.
Preheat and Fast Preheat
Whenever a cooking mode is set and the oven is heating,
the preheating starts, during this period, the instantaneous
temperature is displayed together with the thermometer icon.
As soon as the 100% is reached, the control sounds an
“end of preheat” tone and the current temperature value
disappears.
When it’s necessary to heat up the oven rapidly, a Fast
Preheat mode is available: it uses the heating elements and
the convection fan in a special way, in order to reduce the
heating time as long as possible.
After having set one of the cooking functions for which the
fast preheat is available and set the desired temperature
value touch the key, after entering the functions menu,
select the icon by means of the keys and confirm
by means of the key .
As soon as the set-point temperature is reached, the control
sounds a and both “Fast Preheat Icon” and “current
temperature” disappear. The oven switches automatically to
the desired cooking mode that was previously set: put the
food inside now.
Timer
WARNING
The timer on your oven does not turn the appliance on or off,
its only purpose is to alert you through the buzzer. When
you want to turn off the oven automatically, use the end-of-
cooking or delayed cooking function.
NOTE Pressing the OFF button does not reset or stop the
timer.
1. Press the button and set the desired time using the
arrows and confirm with the button . To switch
the selection between hours and minutes use the arrows
.
2. The time can be set from 1 minute to 12 hours and 59
minutes and, when set, the remaining time is always
visible in the bottom status bar until the time expires or is
reset.
3. To change or cancel the time set, you must reset the timer
by pressing and holding the button for a few seconds.
4. Timer format is usually HR:MIN, switching into MIN:SEC
during the last minute.
5. When the time expires, the display shows 00:00 and the
buzzer will sound for one minute or until the button is
pressed.
