EN
6
INSTALLATION ON SOLID SURFACE
4 5/8” (11.6)
2 3/4” (7.0)
7 1/2”
(19.2)
5” (12.8)
4 7/8” (12.5)
1 3/4” ( 4.5)
HOLE FOR GAS 3½” (9)
HOLE FOR ELECTRICAL 3½” (9)
1 3/4” ( 4.5)
B
CUTOUT FOR FIXING BRAKETS
A
max 25 1/2” (65)
min 24” (61)
INSTALLATION WITHOUT SEPARATOR SHEET
7” (17.9)
2” (5
)
2” (5
)
min 24” (61)
max 25 1/2” (65)
2” (5)
A
2 - Product Dimensions and Cutout Requirements
