26
SOLO6 - TWIN6 - SUB12
Professional Analogue Monitoring System - User Manual
EN
Performance SOLO6 TWIN6
• Frequency response (@ -3dB) 45Hz - 40kHz
• Low cut-off frequency (@ -6dB) 40Hz
• Focus mode 110Hz - 10kHz
• Maximum SPL
(Average CEA2034 50–10kHz free field @ 1m) 110dB 112dB
• Focus mode
(Average CEA2034 100–10kHz free field @ 1m) 109.5dB 111.5dB
Electronic section
• Input Balanced XLR 10kΩ
• Bass amplifier stage 80W RMS 2 x 70W RMS
• Treble amplifier stage 50W RMS
• Nominal power supply ~100-120 VAC/220-240 VAC
50/60Hz
• Rated power consumption 100W 150W
• User controls Sensitivity, stand-by HPF,
LF Shelv, LMF EQ, HF Shelv
Sensitivity, stand-by,
Left/Right, HPF, LF Shelv,
LMF EQ, HF Shelv
• Fuses ~100-120V, T2.5AL/250V
~220-240V, T1.25AL/250V
~100-120V, T3.15AL/250V
~220-240V, T1.6AL/250V
Transducers
• Bass 6.5" (16.5cm) “W” cone 2 x 6.5" (16.5cm) “W” cone
• Treble 1.5" (38mm) Beryllium
• Shielding no
Loudspeaker
• Construction 7/8" (22mm) MDF
• Finish Dark red natural veneering side panels, black body
• Dimensions (HxWxD) 13 1/8 "x9 3/4 x11 5/8 "
(334x246x295mm)
10 1/8 x20 1/4 x13 1/2 "
(258x514x344mm)
• Weight 28.6lbs (13kg) 48.5lbs (22kg)
• Temperature range During use: 5-35°C
In storage: 0-50°C
All specifications are subject to change.
