6
ENGLISH
Optional Extras
Optional extras can be changed or modified for
quality improvement without any notification.
Contact your dealer for buying these items.
These devices work only with certain models.
The model name or design may be changed due to
the manufacturer’s circumstances or policies.
(Depending upon model)
Wall Mounting Bracket
Make sure to use screws and wall mounts that meet
the VESA standard. Standard dimensions for the wall
mount kits are described in the following table.
A
B
Model
32LT340CBUB
32LT340HBUA
32LT560HBUA
32LT570HBUA
40LT340H0UA
32LT340C9UB
32LT340H9UA
32LT560H9UA
32LT570H9UA
40LT560H0UA
40LT570H0UA
43LT340C0UB
43LT340H0UA
43LT560H0UA
43LT570H0UA
43LT340C9UB
43LT340H9UA
43LT560H9UA
43LT570H9UA
VESA (A x B) 200 x 200
Standard screw M6
Number of screws 4
Wall mount
bracket(optional) LSW240B
MSW240
Model
49LT340C0UB
49LT340H0UA 49LT560H0UA
49LT570H0UA
VESA (A x B) 300 x 300
Standard screw M6
Number of screws 4
Wall mount
bracket(optional) OLW480B
MSW240
Lifting and Moving the TV
When moving or lifting the TV, read the following to
prevent the TV from being scratched or damaged and
for safe transportation regardless of its type and size.
• It is recommended to move the TV in the box or
packing material that the TV originally came in.
• Before moving or lifting the TV, disconnect the
power cord and all cables.
• When holding the TV, the screen should face away
from you to avoid damage.
• Hold the top and bottom of the TV frame firmly.
Make sure not to hold the transparent part, speaker,
or speaker grille area.
• Use at least two people to move a large TV.
• When transporting the TV by hand, hold the TV as
shown in the following illustration.
• When transporting the TV, do not expose the TV to
jolts or excessive vibration.
