Preparations
O I
A 3 0 0 A C T IV E SP E A K E R SYS T E M
RCA audio cable
CD player/music player/PC
PC or Mac
USB cable
Fiber optic input
audio cable
TV/CD player
/ Blu-ray player
CD player
/ decoder
XLR cable
O I
A 3 0 0 A C T IV E SP E A K E R SYS T E M
Use the speaker connecting
cable included for connection
CD player
1.Connect speakers
2. Connect to playback devices
3.Connect to power source
O I
A 3 0 0 A C T IV E SP E A K E R SYS T E M
Connect the power cable included to power
input port on the rear panel, and then insert
power plug into wall outlet.
Preparations
4.Speaker placement
* Place the passive and active speaker
on a solid, leveled and steady surface.
For the optimum sound positioning
and layering, using the special stands
of A300 is recommended.
* For the optimum stereo sound effect,
the listener can slightly adjust speaker
angel.
* For the most accurate sound and
balance, the listener should be in the
axis of equilateral triangle formed by
the active and passive speakers.
* High frequency has a much higher
directivity, and for more accurate
sound effect the speaker's tweeter
should be at ear level of the listener.
Passive speaker Active speaker
5.Turn on main power
* After all cables are connected securely, press
power switch on the rear panel to turn on
main power;
* Press the “ ” on the remote control to turn
off power source or switch to standby state;
* LED indicator will be lit to show current audio
mode, please select the correct audio source
with the corresponding connection.
O
Power
9 10
Coaxial cable
O I
A 3 0 0
A C T IV E SP E A K E R SYS T E M
IN P U T B A S S T R E B L E / V O LU M E
L SPEAKER OUT
BALANCED IN
OFF ON
100-240V~50/60Hz 800mA
POWER
AC~INPUT
L
R
LEFT SPEAKER
L SPEAKER OUT
English English
CD player
