ENG - 7
02 PRODUCT OVERVIEW
Top Panel of the Soundbar
2 4
3
1
1 LED indicator
The LED Indicator flashes, glows, or changes color depending on the Soundbar’s current mode or status. The color of the LED indicator
and the number of lights indicate the active mode as described below.
W
White LED
W
White LED
M
Multicolor LED
W
White LED
W
White LED
• The Multicolor LED changes to White , Cyan , Green , Red , and Blue depending on the mode or status.
2 (Multi Function) Button
• In standby mode, press the (Multi Function) button to turn on the Soundbar.
• Press the (Multi Function) button to change the mode. Each time you change the mode, the LED lights in white and then turns off.
LED indicator
White On → Off White On → Off White On → Off
“ TV ARC ” “ Wi-Fi ” “ Bluetooth ”
3 (Volume) Button
Adjusts the volume.
4 (Mic On/Off) Button
Press the button to turn the microphone on or off.
When the microphone is off, the LED indicator will light red.
LED indicator
Red On
“ Mic Off ” “ Mic On ”
• When you plug in the AC cord, the power button will begin working in 4 to 6 seconds.
• When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.
• If you hear sounds from both the TV and Soundbar, go to the
Settings menu for the TV audio and change the TV speaker to External Speaker .
• You can turn on and off audio feedback by using SmartThings app. To learn about using the SmartThings app, refer to “ Method 2. Connecting
via Wi-Fi (Wireless Network) ”.
