ENG - 11
12
TONE CONTROL
By pressing the button, you can adjust the volume of the treble or bass sound. The defired item can be adjusted
using the
Up / Down buttons. This function is enabled in Sound mode excluding in Standard mode.
• To control the volume of the treble or bass sound, select “ Treble ” or “ Bass ” in Sound Settings, and then adjust
the volume between -6~+6 by using the Up / Down buttons.
• Once the bass level is changed, the woofer level will be also adjusted accordingly.
LED indicator
White Blinks X1
“ Treble ” → “ Bass ”
13
Sound Control
By pressing the button, you can set the audio function. The desired item can be adjusted using the Up / Down
buttons. Each time the mode changes, the Multicolor LED blinks in white.
LED indicator
White Blinks X1
“ SpaceFit Sound ” → “ Active Voice Amplifier ” → “ Voice
enhancement ” → “ Night Mode ” → “ Sync ” → “ Virtual ”
• Voice enhancement makes it easier to hear spoken dialog in movies and TV.
• Night Mode is optimized for night time viewing with the settings adjusted to bring the volume down but keep
the dialog clear.
• Press and hold the (Sound Control) button for about 5 seconds to adjust the sound for each frequency band.
150Hz, 300Hz, 600Hz, 1.2kHz, 2.5kHz, 5kHz, and 10kHz are selectable using the Left / Right buttons and each
can be adjusted to a setting between -6 to +6 using the Up / Down buttons.
(Make sure the Sound mode is set to “ STANDARD ”.)
• If the video on the TV and audio from the Soundbar are not synchronized, select “ Sync ” in Sound Control, and
then set the audio delay between 0~300 milliseconds by using the Up / Down buttons.
• “ Sync ” is only supported for some functions.
• The Virtual function can be turned On / Off by using the Up / Down buttons.
14 USB port (C-type)
for charging
The LED lights while charging. When fully charged, the LED turns off.
• The USB Cable is not provided.
• When the remote control does not work due to low battery, charge it by using the USB-C type port.
Active Voice Amplifier (AVA)
• Analyzes external noise in real time while soundbar is playing, so that voice audio can always be heard clearly.
• No data is saved during the analysis.
Using the Hidden Buttons (Buttons with more than one function)
Hidden Button
Reference page
Remote Control Button Function
WOOFER (Up) TV remote control On/Off (Standby) page 13
Up ID SET page 9
(Sound Control) 7 Band EQ page 11
(Source) Audio Feedback On/Off (Standby) page 9
