Description of your dishwasher Description of your dishwasher
31 30
GB GB
The above photograph of the machine with the lower basket removed
shows you all the main components described in these operating
instructions.
Regenerating
salt reservoir
Waste filters
Washing product
container
Rinsing agent
container
Lower sprinkling
arm
Information
plate (After-
Sales service
reference)
Drying valve
(depending on
the model)
Upper basket
Main filter
Anti-blocking
size wire
Your dishwasher is fitted with safety systems protecting you from flood-
ing:
The ANTI-OVERFLOW SYSTEM. This system automatically activates
the drain pump if the water in the tub reaches an abnormal level.
The ANTI-LEAK SYSTEM. This system cuts off the water supply if a
leak is detected under the machine.
The ANTI-BURSTING HOSE. This reinforced water supply hose is fit-
ted with a mechanism that cuts off the water supply directly at the tap
if a water leak occurs.
O N / O F F: P r e s s
this button to
switch your dish-
washer on.
S TA RT / C A N C E L :
Pressing this button
starts this pro-
gramme. Holding
the button pressed
down for 2 seconds
cancels the pro-
gramme.
SALT LIGHT: This
indicates that
there is no regen-
erating salt.
RINSING LIGHT: This
indicates that there is
no rinsing liquid.
PROGRAMME
B U T T O N S :
Press one of
these but-
tons to select
your pro-
gramme.
The DISPLAY
shows the length
of the pro-
gramme, the
delayed start
time and the
water hardness
setting.
DELAYED START:
Press this button to
delay the end of the
programme by 1 to
24 hours.
Rotating nozzle
(depending on
the model)
