4 6178-2010
DIP-Switches
1 2 3 4 5 6 7 8
0 = off 1 = on x = dont care
SW 1 Description Related
AT-commands
0 0 x x Standard dial-up
0 1 x x Leased Line, Answering ATE0Q1&C1&A1
1 1 x x Leased Line, Originating ATE0Q1&C1&A1
x x 1 x Do not abort if unwanted characters
are received during connection
AT&A1
x x x 1 Escape sequence disabled
(all commands ignored in on-line mode)
ATE0Q1&C1
SW 2
0 x x x x x x x
2-8 are not used
1 x x x x x x x For use of SW2:2 to 7
1 0 0 x x x x x Asynchronous communication
1 1 0 x x x x x Synchronous, external clock. Clock from D-Sub pin 24
1 0 1 x x x x x Synchronous, internal clock.
The modem generates the clock
1 1 1 x x x x x Synchronous slave. Clock from line
1 x x 1 x x x x DTR/DSR disconnected AT&S0&D0&C0
SW 3
0 x x x x x x x
4-wire line connection
1 x x x x x x x 2-wire line connection
x 1 x x x x x x Flow control off AT&K0
x x 1 x x x x x REL-mode disbled AT\N0
x x x 1 x x x x Speaker off ATM0
x x x x x 1 x x PLC settings ATQ1E0&C1&K0&A1
x x x x x x 1 x DCD follows the state of the line carrier AT&C1
x x x x x x x 1 Line monitor disabled and no re-training AT%E0
SW 4
0 0 0 0 x x x x
Automatic detection of serial speed and format
1 0 0 0 x x x x 300 bit/s
0 1 0 0 x x x x 600 bit/s
1 1 0 0 x x x x 1 200 bit/s
0 0 1 0 x x x x 2 400 bit/s
1 0 1 0 x x x x 4 800 bit/s
0 1 1 0 x x x x 9 600 bit/s
1 1 1 0 x x x x 19 200 bit/s
0 0 0 1 x x x x 38 400 bit/s
1 0 0 1 x x x x 57 600 bit/s
x x x x 0 0 0 x 7 bits no parity [7N]
x x x x 1 0 0 x 7 bits even parity [7E]
x x x x 0 1 0 x 7 bits odd parity [7O]
x x x x 1 1 0 x 8 bits no parity [8N]
x x x x 0 0 1 x 8 bits even parity [8E]
x x x x 1 0 1 x 8 bits odd parity [8O]
x x x x 0 1 1 x Direct mode [8E] or [8O] in command mode AT\N1
x x x x 1 1 1 x Direct mode [7E] or [7O], [8N] in command mode AT\N1
x x x x x x x 1 2 stop bits
SW 5
0 0 0 0 x x x x
Use saved parameters
1 0 0 0 x x x x V.21, 300 bit/s ATF1
0 0 1 0 x x x x V.22, 1 200 bit/s ATF4
1 0 1 0 x x x x V.22 bis 2 400 bit/s ATF5
0 1 1 0 x x x x V.32 bis 4 800 bit/s ATF6
1 1 1 0 x x x x V.32 bis 7 200 bit/s ATF7
0 0 0 1 x x x x V.32 bis 9 600 bit/s ATF8
1 0 0 1 x x x x V.32 bis 12 000 bit/s ATF9
0 1 0 1 x x x x V.32 bis 14 400 bit/s ATF10
1 1 0 1 x x x x V.34 19 200 bit/s ATF11
0 0 1 1 x x x x V.34 24 400 bit/s ATF12
1 0 1 1 x x x x V.34 28 800 bit/s ATF13
0 1 1 1 x x x x V.34 33 600 bit/s ATF14
1 1 1 1 0 x x x Auto detect mode V.32 bis ATF0
1 1 1 1 1 x x x Auto detect mode V.34
