Westermo TD-32 B - Manuel (Page 20)

Telephone
Exchange Telephone
Exchange
Dial up line 2-wire
Telephone
modem
4-position
screw terminal
RJ-12 connection
Telephone
Exchange Telephone
Exchange
Dial up line 2-wire
Telephone
modem 3
4
4-position
screw terminal
Leased line 2-wire
4-position
screw terminal
Leased line 4-wire
Typical TD-32 B line connections
Typische Anschlußarten beim TD-32 B
Exempel på linjeanslutningar med TD-32 B
TD-32 B connexion de ligne (typique)
