5
■ Flexible conduit from the oven should be connected directly to
the junction box.
■ Do not cut the conduit. The length of conduit provided is for
serviceability of the oven.
■ A UL listed or CSA approved conduit connector must be
provided.
■ If the house has aluminum wiring follow the procedure below:
1. Connect a section of solid copper wire to the pigtail
leads.
2. Connect the aluminum wiring to the added section of
copper wire using special connectors and/or tools
designed and UL listed for joining copper to aluminum.
Follow the electrical connector manufacturer's recommended
procedure. Aluminum/copper connection must conform with
local codes and industry accepted wiring practices.
INSTALLATION INSTRUCTIONS
Prepare Built-In Oven
1. Decide on the final location for the oven. Locate existing
wiring to avoid drilling into or severing wiring during
installation.
2. To avoid floor damage, set the oven onto cardboard prior to
installation. Do not use handle or any portion of the front
frame or trim for lifting.
3. Remove the shipping materials and tape from the oven.
4. Remove the hardware package from inside the bag containing
literature.
5. Remove and set aside racks and other parts from inside the
oven.
6. Move oven and cardboard close to the oven’s final location.
7. Open the oven door.
Remove Oven Door.
IMPORTANT: Use both hands to remove oven doors.
1. Open oven door to the full open position.
2. Locate the oven door latches in both corners of the oven door.
3. Using a Phillips screwdriver, remove the screw and door hinge
cover plate above each door latch slot in the oven frame.
4. Grasp the edges of the oven door with both hands and close
the oven door halfway. Lift and pull oven door toward you and
remove. Set the oven door aside on a covered surface.
WARNING
Excessive Weight Hazard
Use two or more people to move and install oven.
Failure to do so can result in back or other injury.
A. Hinge cover plate screw
B. Hinge cover plate
C. Hinge
A
B
C
