Panneau arrière
Voir la page indiquée entre parenthèses ( ).
o
q w e r t y u i
Q0 Q5 Q2 Q3 Q4 Q1
q Borne RS-232C ········································································· ( 68 )
w Bornes d’antennes FM/AM ···················································· ( 15 )
e Bornes audio analogiques ························ ( 11 , 12 , 13 , 15 , 16 , 17 )
r Bornes PRE OUT
·················································· ( C 6 , 17 , 60 , 61 , 62 , 63 , 64 , 65 )
t Bornes VIDEO ························································ ( 10 , 11 , 12 , 13 )
y Bornes COMPONENT VIDEO ······································ ( 10 , 11 , 12 )
u Bornes d’enceintes
························································ ( C 6 , 60 , 61 , 62 , 63 , 64 , 65 )
i Prise CA (AC IN) ································································· ( C 5 )
o Bornes HDMI ·································································· ( C 3 , 8 )
Q0 Bornes audio numériques ·········································· ( 10 , 12 , 15 )
Q1 Borne NETWORK ····································································· ( 18 )
Q2 Prise FLASHER IN
Utilisé avec un BOITIER de commande ou autre dispositif de
commande pour la gestion de cet appareil.
Q3 Prises REMOTE CONTROL ······················································ ( 68 )
Q4 Prise Borne M-XPort ······························································· ( 16 )
Q5 7.1CH IN connectors ································································ ( 16 )
REMARQUE
Ne touchez pas les broches internes des connecteurs sur le panneau
arrière. Une éventuelle décharge électrique pourrait endommager de
façon permanente votre appareil.
