Fulgor Milano 700 Series 36 Inch Induction Cooktop Use and Care - Manuel (Page 15)

EN
11
Power level
The power level of the cooking area can be set from level 1
to level 9. A further level P (Power Booster) is available that
allows a very rapid heating of food and, therefore, saves you
time. The power level represented by an intermittent letter “A”
is the activation of the automatic heating function.
Booster and power management
The generator, with Booster enabled, provides an individual
cooking area power that is significantly higher than the rated
power; the display of the selected cooking area shows a “P”.
The Booster function can be activated by pressing at the end
of the cursor of the cooking area (11) . The power increase is
different depending on the size of the cooking area:
1. For a cooking area with a diameter of 5 3/4” (145 mm),
the power goes from a level 9 of 1400 W to the Booster
level of 2200 W for 10 minutes.
2. For a cooking area with a diameter of 7” (180 mm), the
power goes from a level 9 of 1850 W to the Booster level
of 3000 W for 10 minutes.
3. For a rectangular cooking area 7 1/2” x 8 1/2” (190 mm
x 220 mm), the power goes from a level 9 of 2000 W to
the Booster level of 3600 W for 10 minutes.
4. For a cooking area with a diameter of 11” (280 mm), the
power goes from a level 9 of 2300 W to the Booster level
of 3600 W for 10 minutes.
For safety reasons, the Booster function has a limited duration
(10 min), after 10 min the zone is reduced to level 9.
If the cooking vessel is removed from the cooking area during
the Booster time, the Booster remains active and the Booster
time is not deactivated. With the Booster activated, changing
the value set with your finger in the cursor area deactivates
the Booster. The Booster function “P” can be activated in all
cooking areas, but priority is given to the last Booster activated,
reducing any other cooking levels.
36” Power sharing table
LEFT CENTRAL RIGHT
9 P 6 P
P
P 8 P 6
30” Power sharing table
CENT/RIGHT RIGHT
P 6 P 8
7 P 9 P
Automatic preheating (or “heat-up” function)
This feature makes cooking easier by adding ‘boil and reduce’
functionality to the elements. The surface automatically heats
up at Full Power and then returns to the selected power level
after a certain time (see Table).
Activating automatic heating (or “heat-up” function)
Press and hold an area of the cursor for the cooking area that
is working for about 3 seconds until you hear a beep (such as
1/3 of the length of the cursor area). For example: Select level
3 and activate the automatic heating function by pressing your
finger for 3 seconds. The corresponding display shows the
letter “A” alternating with “3”. With these settings, the cooking
surface heats the cooking area at the maximum level “9” for 2
minutes and then continues cooking level at level “3”.
Power livel Duration Automatic
Heating Function
(time in minutes)
Maximum time
elements will operate
at power setting (time
in minutes)
0 -
1 0m 40s 516
2 1m 12s 402
3 2m 318
4 2m 56s 258
5 4m 16s 210
6 7m 12s 138
7 2m 138
8 3m 12s 108
9 - 90
P - 10
Bridge function (For large pans)
This function facilitates cooking with elongated pans, is only
available for the rectangular cooking areas and is activated
by simultaneously pressing the 2 cursors of the 2 cooking
areas involved. At this point, a “ ” icon will light up next
to the display of the levels and the cooking area can now
be controlled from only once cursor since the other will work
simultaneously at the same level. Once set to bridge mode,
the leftmost of the two sliders becomes the master controller
for both elements. To disable bridge mode, simply touch both
slider controls simultaneously at any point along the adjustment
bars.
Special functions (low temp)
This function is available in each cooking area and its activation
is indicated by one of the two dedicated icons (17 & 18). It is
possible to activate 2 “cooking” levels:
1. Melting with a temperature of approximately 45°C.
2. Simmering with a temperature of approximately 70°C.
These temperatures are approximate and are greatly
dependent on the pot and the quantity of food.
After turning on the desired heating zone by pressing the key
