LG 23.8" Full HD All-in-One Thin Client PC - Manuel (Page 19)

19
ENGLISH
Connecting monitor
DisplayPort Connection
Transmits the PC's digital video and audio signals to the monitor. Connect your monitor which is supported DP
using the DisplayPort cable.
NOTE
• There may be no video or audio output depending on the DP (DisplayPort) version of the PC.
USB-C connection
Transmits digital video and audio signals from your PC to the monitor.
NOTE
• DP Alternate Mode (DP over USB-C) are supported via USB-C Port.
• Features may not work properly depending on the connected device’s specifications and the environment.
• Connect Adapter to supply power to the Monitor.
Connecting LAN
LAN connection
Connect the router or switch to the monitor.
NOTE
• The LAN cable is sold separately.
• The following LAN cable type can be used: Standard: IEEE 802.3 ETHERNET
• Connect the LAN cable and the peripheral devices to use the cloud monitor.
SFP connection
(SFP supported models only.)
NOTE
• Only supports 1 Gbps module. (155 Mbps, 10 Gbps (SFP+) are not supported)
• When you choose the SFP module, refer to the compatibility list by SFP vendor.
• Use the same SFP module to connect both devices.
• Devices are sold separately.
