30
ENGLISH
16 Tune Command (Command: m a)
* This command may work differently Depending
upon model and signal.
* For Europe, Mid-East, Colombia, Asia except South
Korea and Japan Model
► Select channel to following physical number.
Transmission
(m)(a)( )([Set ID])( )(Data 00)( )(Data 01)
( )(Data 02)(Cr)
• Analog Antenna/Cable
(Data 00)(Data 01) Channel Data
Data 00: High byte channel data
Data 01: Low byte channel data
- 00 00 ~ 00 C7 (Decimal: 0 ~ 199)
Data 02: Input Source (Analog)
- 00: Antenna TV (ATV)
- 80: Cable TV (CATV)
• Digital Antenna/Cable/Satellite
(Data 00)(Data 01): Channel Data
Data 00: High byte channel data
Data 01: Low byte channel data
- 00 00 ~ 27 0F (Decimal: 0 ~ 9999)
Data 02: Input Source (Digital)
- 10: Antenna TV (DTV)
- 20: Antenna Radio (Radio)
- 40: Satellite TV (SDTV)
- 50: Satellite Radio (S-Radio)
- 90: Cable TV (CADTV)
- a0: Cable Radio (CA-Radio)
13 [Balance] (Command: k t)
► To adjust balance. You can also adjust balance in
the audio settings.
Transmission
(k)(t)( )([Set ID])( )(Data)(Cr)
Data Min: 00 to Max: 64
Ack
(t)( )([Set ID])( )(OK/NG)(Data)(x)
14 [Color Temperature] (Command: x u)
► To adjust color temperature. You can also adjust
color temperature in the picture settings.
Transmission
(x)(u)( )([Set ID])( )(Data)(Cr)
Data Min: 00 to Max: 64
Ack
(u)( )([Set ID])( )(OK/NG)(Data)(x)
15 [Equalizer] (Command: j v)
► Adjust EQ of the set.
Transmission
(j)(v)( )([Set ID])( )(Data)(Cr)
0 0 0 0 0 0 0 0
MSB
Frequency Data
LSB
7 6 5 Frequency 4 3 2 1 0 Step
0 0 0 1st Band 0 0 0 0 0 0(decimal)
0 0 1 2nd Band 0 0 0 0 1 1(decimal)
0 1 0 3rd Band ... ... ... ... ... ...
0 1 1 4th Band 1 0 0 1 1 19(decimal)
1 0 0 5th Band 1 0 1 0 0 20(decimal)
Ack
(v)( )([Set ID])( )(OK/NG)(Data)(x)
* It depends on model, and can adjust when sound
mode is EQ adjustable value.
