Neck strap and caps during observation
Neck strap
Attach the neck strap as illustrated (A), paying special attention to avoid twisting the strap.
Attach the objective lens caps (B), making sure the cap part hinges open downward from the binocular tube
when folded open. The slit should be visible at the left side of each binocular tube, viewed from the eyepiece
side, to confirm correct positioning (8x42/10x42). Correctly attached when supplied.
Eyepiece cap
There are two ways you can position the eyepiece cap as you observe your subject.
・ Remove the eyepiece cap from the eyepieces and allow it to hang from the neck strap.
・ Remove the eyepiece cap from the eyepieces, then detach the right strap from the cap and allow it to
hang from the left neck strap (C).
To attach/detach caps from the neck strap as shown in image (D) in the following order:
・ Attaching: c → b → a
・ Detaching: a → b → c
Flipdown objective lens caps
The binoculars are used with the objective lens caps folded open (C).
Please refer to images A, B, C and D on page 3.
