Drawbar eyes
DIN
Nennmaße
Pivot angle
a
(mm)
b
(mm)
c
(mm)
horizontal vertical
74054
100
40
30,5
min. 90
°
min. 20
°
11026
100
40
42
min. 90
°
min. 22
°
74043
100
40
32
min. 90
°
min. 20
°
9678
110 –120
50
30
min. 60
°
min. 20
°
Switzerland* 115
40
40
min. 90
°
min. 20
°
* only ROi847 B
Do not use any other drawbar eyes: risk of accident!
