MEDC XB15 Manuel d'utilisation
Page 4
02/15
© MEDC 2015
GENERAL ARRANGEMENT
Light Output Ratings
4.0 MAINTENANCE
During the working life of the unit, it should require little or no maintenance. GRP will resist attack by most
acids, alkalis and chemicals and is as resistant to concentrated acids and alkalis as most metal products.
However, if abnormal or unusual environmental conditions occur due to plant damage or accident etc.,
then visual inspection is recommended.
If the unit requires cleaning, then only clean exterior with a damp cloth to avoid electro-static charge build up.
Replacement of the xenon tube (see below) can be carried out by competent site personnel. Other repairs
should be undertaken by returning the unit to MEDC or by an authorised repairer of Ex equipment.
If a unit fault should occur, then the unit can be repaired by MEDC. All parts of the unit are replaceable.
If you acquired a significant quantity of units, then it is recommended that spares are also made available.
Please discuss your requirements with the Technical Sales Engineers at MEDC.
Ш
4-41/64”
Ш
118mm
9-13/32”
240mm
9-11/64”
233mm
Ш
5-29/32”
Ш
150mm
1-7/16” A/F
36mm A/F
3-35/64”
90mm
2-23/64”
60mm
2-23/64”
60mm
3-35/64”
90mm
19/32”
15mm
DIRECT MOUNT VERSION (CAST GUARD SHOWN)
PIPE MOUNT VERSION (WIRE GUARD SHOWN)
FIXING HOLES
2-23/64”
60mm
2-23/64”
60mm
8-17/64”
210mm
Ш
5-29/32”
Ш
150mm
Ш
21/64”
Ш
8.5mm
2 POSITIONS
25/32”
20mm
1-17/32”
39mm
9-13/32”
239mm
9”
228.5mm
VOLTAGE
LIGHT OUTPUT RATING (Cd)
NO GUARD
WIRE GUARD
CAST GUARD
24VDC
60
50
24
48VDC
50
45
20
REG. 120Vac
30
25
12
REG. 240Vac
30
25
12
COLOURED LENSES MULTIPLYING FACTOR
RED
BLUE
GREEN
AMBER
YELLOW
0.2
0.27
0.24
0.36
0.65
