Accessories
Please make sure the following items are included with your LCD TV. If any items are
missing, contact your dealer.
Remote Control &
Batteries (AAAx 2)
Owner’ s
Instructions
SPEAKER
REMOTE CONTROL SENSOR
Aim the remote control towards this
spot on the TV.
POWER INDICATOR
Green: In power on mode.
Red: In standby mode.
Toggles between all the available input
CH+/-
Press to change channels. In the on-screen menu, use the CH +/-
buttons as up/down arrow buttons.
VOL+/-
Press to increase or decrease the volume.
In the on-screen menu, use the VOL +/-
buttons as left/right arrow buttons.
POWER
Press POWER button to toggle between normal and standby mode.
MENU
Press to see an on-screen menu of your
TV's features.
SOURCE
4
5
6
8
sources ( TV, AV, PC) Componente, HDMI 1, HDMI 2, HDMI 3,
General Description
Overview of front and side panel
Warranty Card
Assembllng
Stand Process
7
4
General Description
Overview of back panel
COAXIAL
OUT
RF
IN
VGA
IN
PC AUDIO
IN
HDMI 1 HDMI 2 HDMI 3
1 2 3 4 5 6 7 8
Pr VIDEO R L VIDEO R
9 10
Pb Y L
11
OUT
1.
2.
COAXIAL: output
RF: input
3. VGA(PC): input
4. PC AUDIO: input
5. HDMI 1: input
6. HDMI 2: input
7. HDMI 3: input
8. SERVICE PORT
9. VIDEO: output
10. VIDEO: input
11. YPbPr: input
SERVICE
PORT
