1 CLASS 1
LASER PRODUCT
24
8. DVD Operation
Basic operation
1. Turn ON and OFF the DVD function
- Turn on the LCD TV and then press SOURCE button to select DVD mode.
2. Playback
- Insert DVD discs, with printed label side facing backward.press button will enter the disc menu.
Press button to start in sequence. For others, while stopped, press the button to start in sequence.
3. Program playback
- Using Program playback, you can select max. 16 chapters from the disc to playback in programmed order.
- OSD for program playback as below.
MP3/JPEG Playback
After loading and scaning the MP3 / JPEG CD&DVD, it will initially display the MP3 contents automatically and start to play the
first
file (highlighted file). Screen as follow:
- Us ing the navigation buttons enables you to check you favorite folder and playback the first file or mo ve to the your favorite folders.
NOTE:
- Press ◄ ► buttons to move the highlighted files to folders, documents or mode selection.
- Press numeric buttons to select the contents directly. For number over 10, press +10 button first. (e.g. File number 15,
press +10 then 5.)
- When playing MP3 files, there is no picture display, only audio output.
- Playing JPEG discs : Press the PROGRAM button to select slide effects. There are 17 slide modes, press the PROGRAM
button to toggle between different modes in sequence. (Start from top Start from bottom Start from left Start from right
Start from upper left corner Start from upper right corner Merge from left / right Horizontal blades Vertical blades Merge
form 4 corners Random Playback Slide effect OFF).
- When playing or pauseing images, you may use navigation buttons to flip / rotate the picture.
▲ button to flip horizontally.
▼ button to flip vertically.
◄ button to rotate left 90˚.
► button to rotate right 90˚.
- When playing or pausing images, you may use the D.MENU button to enter preview mode to dislay 12 pictures.
Press / button to select next / previous page or press numeric buttons to view the corresponding pictures.
- The maximum JPEG image size that can be displayed is 1280 x 1024.
Display current
MP3 playback
function
Highlight file for
current playback.
Display current
MP3 playback
function
Scroll bar to view
next page.
Buttons for switching
between MP3 and JPEG
playback function.
WARNING! DO NOT INSERT OR PLAY 8CM DISC, THEY WILL GET STUCK.
As it is usual for DVD movies to be released at different times in different regions of the world, all players have region
codes and discs can have an optional region code. If you load a disc of different region coe into your player you will see
the region code notice on the screen. The disc will not playback and should be unloaded. The region code for thin
player is 1.
