Triangle Voce Ez - Manuel (Page 16)

ESPRIT Ez 16
Pedestal assembly
Step 2- Secure the pedestal by using
the screws and key supplied.
Rubber spike Metal spike
Or
Step 1- Place the rubber insert in the pedestal
Step 2- Placethe metal spike in the rubber insert
Step 3- Place the counter spike under the spikes
to protect your surface.
X4 X4 X4 X4 X4 X1 X1
Spike assembly according to your floor
X4
TRIANGLE DISTRIBUTION FRANCE 41 Rue Borie 33300 Bordeaux FRANCE
1
1
2
2
3
3
4
4
4
2
Step 1- Mount the rubber insert 1
5
5
6
7 6 8
8
7
ESPRIT EZ
Step 1- Stand the speaker
on the top
(be sure to place it on
a non-abrasive surface)
Rigid surface(wood floor) Soft ground (carpet, rug)
Pedestal Assembly for Antal Ez
