Radson Infrared clock ET - Manuel

1 Infrared Thermostat Transmitter with Digital Display - Instructions PPLIMP10314/Bd of 03/03/2011
Infrared receiver
A
B
C
A. Towel radiator pilot light
B. Towel radiator on/standby
button
C. Infrared receiver D. Filter cleaning light
E. Turbo pilot light
F. Towel dryer pilot light
G. Infrared receiver H. Towel radiator on/standby
button
I. Infrared transmitter
Installation and Use
Infrared clock thermostat with or without Turbo
1. Operating mode
2. Transmission indicator
3. Keypad lock activated
4. Exemption programme
5. Heating indicator
6. Day-time programme in Auto mode
7. Current time, programme no. or
parameter name
8. Current day
9. Boost activated
10. Low battery indicator
11. if ON => room temperature displayed
12. Temperature setting or room temperature
Presentation
This infrared transmitter with programmable digital dis-
play is designed to bring you comfort and energy savings.
It allows you to operate your towel radiator by remote
control.
It allows you to regulate room temperature to a desired
temperature (temperature setting).
The Boost function allows you to rapidly increase the
temperature in your bathroom and/or dry your towels.
You can set the room temperature using the sensor on
the transmitter or receiver. By default, the temperature is
set using the sensor on the receiver.
Powering on the device
After connecting your device to the electrical installation:
• Electric or combined towel radiator: Appuyez sur le
bouton on the receiver at the bottom of the device
to turn the towel radiator on. The «A» LED lights up.
• Electric or combined towel radiator with Turbo
option:
Press the «H» button on the side of the Turbo to
turn the thermostat on. The «F» LED lights up.
Infrared clock thermostat
with or without Turbo Infrared receiver for Turbo
D E F G H
ENG
