REVISIONS
ECN # REV. DESCRIPTION DATE BY
8480 1 ISSUED DRAWING 10/4/2010 MDO
PARTS TO BE FREE OF
BURRS AND SHARP EDGES
THIS DRAWING AND ALL INFORMATION CONTAINED HEREIN IS AND REMAINS THE PROPERTY OF ARDISAM INC.
AND IS CONFIDENTIAL. IT IS SUBMITTED AND MAY BE USED ONLY IN CONNECTION WITH ARDISAMS' PROPOSALS
AND/OR ITS CUSTOMERS' ORDERS. IT SHALL NOT BE DISCLOSED TO OTHERS OR COPIED WITHOUT ARDISAMS'
SPECIFIC WRITTEN CONSENT AND SHALL BE IMMEDIATELY RETURNED UPON REQUEST.
MATERIAL TOLERANCE UNLESS
OTHERWISE NOTED:
0.0 ±.100 INCH ± 2.54 MM
0.00 ±.030 INCH ± 0.76 MM
0.000 ±.010 INCH ± 0.25 MM
ANGLES:
0 ± 2°
0.0 ± 1.0°
THREADS CLASS 2
PRIMARY DIMENSIONS ARE IN INCHES
SECONDARY DIMEMSION ARE IN MM
ALL ANGLES ARE DECIMAL DEGREES
UNLESS OTHERWISE SPECIFIED
NAME
TREATMENT
DR BY APPD PRT NO W1200
PT WEIGHT SURFACE AREA DATE REVISION
THIRD ANGLE PROJECTION
SEE BILL OF MATERIALS
NONE
32023.47 3424787.55
W1200 5 TON ELECTRIC
LOG SPLITTER
1
MATT OLSEN MDO 9/17/2010
09/17/2010 SHEET: 1 OF 8
Spécifications sujettes à changement sans préavis
© 2010 SBI Accessoires de chauffage
AVIS : NOUS NE SOMMES PAS RESPONSABLES DES ERREURS TYPOGRAPHIQUES.
Manuel de l’utilisateur
Instructions originales d’utilisation
FENDEUSE DE BÛCHES ÉLECTRIQUE
SpLITz-IT 5-TON
FRANÇAIS
Pièce d’origine # AC02585
SBI AcceSSoIreS de chAuffAge
250 rue de copenhague | saint-augustin-de-desmaures
québec, canada g3a 2h3
