Maytag WOD93EC7AW - Manuel (Page 5)

5
OVEN USE
Odors and smoke are normal when the oven is used the first few
times or when it is heavily soiled. IMPORTANT: The health of some birds is extremely sensitive to the
fumes given off. Exposure to the fumes may result in death to
certain birds. Always move birds to another closed and well-
ventilated room.
Electronic Oven Controls
Control Display
The display will light up when first powered up or after a power
loss. When oven is not in use, the time of day is displayed.
Tones
Tones are audible signals, indicating the following:
One Tone
■ Valid keypad press.
■ Oven is preheated (long tone).
■ Kitchen timer (long tone with reminder tone every 60 seconds).
■ Function has been entered.
Three Tones
■ Invalid keypad press.
Four Tones
■ End of cycle (with reminder tone every 60 seconds).
Use the Settings/Clock keypad to change the tone settings.
Settings
Many features of the oven control can be adjusted to meet your
personal needs. These changes are made using the Settings/Clock
keypad.
Use the Settings/Clock keypad to scroll through the features that
can be changed. Each press of the Settings/Clock keypad will
advance the display to the next setting. After selecting the feature
to be changed, the control will prompt you for the required input.
Details of all of the feature changes are explained in the following
sections.
Press CANCEL to exit Settings.
Fahrenheit and Celsius
The temperature is preset to Fahrenheit but can be changed to
Celsius.
1. Press SETTINGS/CLOCK until “TEMP UNIT” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
Audible Tones Disable
Turns off all tones, including the end of cycle tone and key press
tones.
1. Press SETTINGS/CLOCK until “SOUND” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
Sound Volume
Sets the pitch of the tone to either high or low.
1. Press SETTINGS/CLOCK until “SOUND VOLUME” is
displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
End of Cycle Tone
Activates or turns off the tones that sound at the end of a cycle.
1. Press SETTINGS/CLOCK until “END TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
Key Press Tones
Activates or turns off the tones when a keypad is pressed.
1. Press SETTINGS/CLOCK until “KEYPRESS TONE” is
displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
Reminder Tones Disable
Turns off the short repeating tone that sounds every 1 minute after
the end of cycle tones.
1. Press SETTINGS/CLOCK until “REMINDER TONE” is
displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
12/24 Hour Clock
1. Press SETTINGS/CLOCK until “12/24 HOUR” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
Demo Mode
IMPORTANT: This feature is intended for use on the sales floor
with 120V power connection and permits the control features to be
demonstrated without heating elements turning on. If this feature is
activated, the oven will not work.
1. Press SETTINGS/CLOCK until “DEMO MODE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
12-Hour Shutoff
The oven control is set to automatically shut off the oven 12 hours
after the oven initiates a cook or clean function. This will not
interfere with any timed or delay cook functions.
1. Press SETTINGS/CLOCK until “12 HR AUTO OFF” is
displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press CANCEL to exit and display the time of day.
