Manuel d’utilisation de la Cybex 18020 Bravo Pull (Tirage)
Avertissements et mises en garde
Les autocollants d’avertissement indiquent une situation potentiellement dangereuse qui peut
entraîner des blessures graves, voire mortelles si les mesures de sécurité ne sont pas respectées.
Les autocollants de mise en garde indiquent une situation potentiellement dangereuse qui peut
entraîner des blessures graves, voire mortelles si les mesures de sécurité ne sont pas respectées.
Les schémas figurant après les autocollants indiquent l’emplacement de chaque autocollant.
