2.MODEL FUNCTION DESCRIPTION
TIME : 0:00~99:59.
SPD : 0.0~99.9 KMH
RPM : 0~15~999
WATT DISPLAY : 0~999
DISTANCE : 0.00~99.99 KM.
CALORIES : 0~9999.
TEMPERATURE : 0~60 / 32~99
GENDOR : GIRL / BOY
AGE : 10-25-99
HEIGHT : 100-160-200 (CM) / 40-60-80 (INCH)
WEIGHT : 20-50-150 (KG) / 40-100-350 (LB)
PULSE : P~30~240
HEART SYMBOL : ON/OFF blinks
MANUAL : 1~16 levels
PROGRAMM : P1~P12
WATT CONSTANT : 10~350 WATTS
PERSONAL : U1~U4
H.R.C : 55% 、 75% 、 90% 、 IND (TARGET)
USER DATA : U0 ~U4 ( U1 ~ U4 memorized user data
3. POWER ON
1.
Plug in 6V 1A power Adaptor to right country socket and connect the I / L PIN to Fitness equipment.
2. Power, U1 is displayed on the screen. Select the user between U1 and U4 with the UP and DOWN
and confirm with the ENTER key
- Once the user selects, U1 appears on the right of the screen, You can choose the sex, age, height, weight
using the Up and DOWN keys and confirm with the ENTER key
3. Recovery ： To test user’s heart recovery extent in fixed time, time will be 1 minute.
4. User Data ： 5 groups for user setting U0~U4, every user can set gender 、 age 、 height and weight,
however when power off or TOTAL RESET,U0 setting files will be cleaned and reset and U1-U4 setting
values will be saved permanently.
5.
USER SETTING VALUE MEMORY: setting files memory (TIME 、 DISTANCE 、 CALORIES 、 PULSE
setting value)&the function setting value(set value which used last time or changed manual load set value: or
PROGRAM PX(1-12)…Etc. it can only remember one of them. For instance: WATT CONSTANT SET
VALUE: or PERSONAL program), U1~U4 fours groups altogether.
