7
GB
MAIN FUNCTIONS OF THE WASHING MACHINE
A Drier selection button
C Optional function buttons
H Spin selector button
I Delayed start button
L Start button
M Delay and wash progress indicator leds
P Programme and temperature knob
S Spin speed indicator leds
T Drying time indicator led
MODEL: Campomatic WD 950 E
USING THE WASHING MACHINE
(Follow these instructions and the washing machine will run the selected wash cycle)
1. Open the door. Load the washing loosely in the drum without compacting it. (Items of different sizes
strengthen the washing action and are distributed better during spinning).
Warning: Do not overload the washing machine. It is not advisable to wash items that absorb
large quantities of water such as carpets.
2. Close the door using a light pressure. Check that none of the items have become trapped between
the door and the gasket.
3. Add a low-suds powder detergent and softener designed for automatic washing machines in the
respective compartments (see chapter “USE OF DETERGENTS).
4. Close the detergent drawer. Do not open the drawer while the machine is working as this may
cause water to spill out.
5. Rotate the programmer knob ( P) to select the programme and required temperature according to
the type of fabric to wash (see: “ PROGRAMME TABLES”), then press the start button (L) and the
cycle will start.
N.B. When a programme is selected, the led indicating the recommended spin speed for the
programme will light up.
6. If the spin speed selected by the washing machine does not meet with your needs, select the
required speed by pressing button ( H). (see “VARIABLE SPIN”).
7. Select the (C) buttons with the required functions (see “OPTIONAL FUNCTIONS”).
8. Press button (I) if required (see “DELAYED START”)
9. Press button (L) to start the wash cycle (see “START BUTTON”)
10. On completion of the wash, rotate the programmer knob (P) to the “STOP” position,
11. With dry hands, unplug the washing machine from the mains supply.
12. Open the door and remove the washing.
13. Close the water feed valve.
WASH CYCLE:
“EASY LOGIC” TECHNOLOGY
The Easy Logic II system automatically reduces the wash time and water and power
consumption according to the amount of washing placed in the drum.
The washing machine will automatically programme a half-load or incomplete load wash cycle
without the need for any intervention.
MAX
800
600
500
30
40
90 75
60
40
30
60
40
30 40 30 40
35
ºC
COLD SILKS - WOOL
RINSES
DRY
DRAIN SPIN
COLD WASH
STOP
DAILY WASH
QUICK
SYNTHETICS DELICATES
WOOL
COTTONS
TURBOLOGIC WD950E
MADE IN ITALY
6KG
RPM 1200
1 H 2 H 4 H 8 H
END
A Class
Washing Efficiency
180'
140'
120'
100'
40'
WASHER DRYER
M P
H C A L I
S T
