ART Pro Audio M-One - Cardioid FET Condenser Microphone - Manuel

w w w . a r t p r o a u d i o . c o m
The M-One cardioid condenser microphone delivers solid quality
and outstanding performance in an extremely cost effective
microphone. The low-mass diaphragm and upgraded high quality
capsule delivers a clear tone with accurate sonic detail making it
perfect for a wide range of recording and live sound applications.
As a cardioid condenser microphone the M-One picks up only
sound directly in front of the mic while sounds from sides and back
of the microphone are rejected increasing isolation and delivering
controlled directionality.
In live sound and remote recording applications, the M-One’s cardioid
pattern offers excellent feedback rejection and better isolation and will
give you the best results on most vocal applications and a wide range
of solo instruments including background brass and woodwinds,
acoustic stringed instruments (violin, viola and cello), drums and
percussion. It offers full frequency response at the front of the
microphone with a very controlled and predictable proximity effect -
the increased low frequency response when microphone is placed
close to sound source.
Vocalists can use the proximity effect to their advantage, adding
fullness and more bottom end to the voice. Experienced vocalists can
easily incorporate it as part of their overall microphone technique.
Note: The cardioid symbol on the microphone housing denotes the
'live side', or front face of the microphone that in all cases should
face the performer.
As a condenser microphone, the ART M-One requires phantom
power to operate. A subtle recessed LED under the gold capsule
behind the microphone windscreen will illuminate when phantom
power is present, and the microphone is operational.
The microphone’s chassis is a precision-tooled zinc/aluminum alloy
with a dent resistant stainless-steel wire-mesh windscreen and
comes with a deluxe, secure, hard-tail microphone standmount.
Description
Features
M - O n e C a r d i o i d
C o n d e n s e r M i c r o p h o n e
▲ Warm, Extremely Smooth-Sounding Design
▲ 32mm Gold Sputtered Diaphragm
▲ Extremely Wide Dynamic Range With Low Noise Floor
▲ Hard-tail Microphone Standmount Included
Specifications:
Type: Cardioid Condenser Microphone
Capsule: 32mm Diaphragm Side Address
Polar Pattern: Cardioid
Frequency Response: 20Hz to 20kHz
MAX SPL: 135dB
S/N Ratio: 78dB
Sensitivity: -35dB (+/-2dB)
Impedance: <200 ohms
Recommended Load Impedance: 1000 ohms
Power Requirement: 48v Phantom Power
Dimensions: 37mm x 175mm / 1.5 inches x 6.9 inches
Weight: 469g / 16oz
Specifications subject to change without notice
