Rev. 1.02 - 12 -
STP-103II
2-2-2 Interface de série de la STP-103II
Imprimante HOTE
1 /STROBE (E/S) 1 /STROBE (E/S)
2 /DATA0 (E/S) 2 /DATA0 (E/S)
3 /DATA1 (E/S) 3 /DATA1 (E/S)
4 /DATA2 (E/S) 4 /DATA2 (E/S)
5 /DATA3 (E/S) 5 /DATA3 (E/S)
6 /DATA4 (E/S) 6 /DATA4 (E/S)
7 /DATA5 (E/S) 7 /DATA5 (E/S)
8 /DATA6 (E/S) 8 /DATA6 (E/S)
9 /DATA7 (E/S) 9 /DATA7 (E/S)
10 ACK (E) 10 ACK (E)
11 OCCUPE (E) 11 OCCUPE (E)
12 PE (E) 12 PE (E)
13 SLCT 13 SLCT
15 ERREUR (E) 15 ERREUR (E)
16~21 N.C 16 INIT (S)
22~25 GND 18~25 GND
FGND FGND
MÂ LE 25 BROCHES MÂ LE 25 BROCHES
2-2-3 Interface USB de la STP-103II
Imprimante (type B) Hôte (type A)
1
VBUS
--------------------- 1
VBUS
2
D-
--------------------- 2
D-
3
D+
--------------------- 3
D+
4
GND
--------------------- 4
GND
