20
Specifications
Monitor
System Liquid crystal color display
Drive system TFT-LCD active matrix
system
Picture size 6.5 inches wide screen (16:9)
144
×
77 mm, 163 mm
(5 3 /
4
×
3 1 /
8
in., 6 1 /
2
in.)
(w
/
h, d)
Picture segment
336,960 (w 1440
×
h 234) dots
Power requirements
12 V DC car battery
(negative ground)
Current drain Approx. 700 mA
Dimensions
164
Ч
103
Ч
29 mm
(6 1 /
2
Ч
4 1 /
8
Ч
1 3 /
16
in.)
(w/h/d)
Operating temperature
5 °C – 45 °C
(41 °F – 113 °F)
Mass Approx. 370 g (13 oz)
Connection box XA-113
A/V Output
Output Impedance: less than 220
Ω
less than 100 pF
Output Level: 0 dBs ±0.3 dB
(0.775 V rms)
(Vol Max)
Video: 75
Ω
1Vp-p
A/V Input
×
2
Input Impedance: more than 10 K
Ω
less than 1000 pF
Input Level: ±1.3 dBs +0/–0.3 dB
(0.775 V rms)
Video: 75
Ω
1 Vp-p
DC output 7.5 V (max 2 A)
Dimensions 150
Ч
42
Ч
80 mm
(6
Ч
1 11 /
16
Ч
3 1 /
4
in.)
(w/h/d)
Mass 250 g (9 oz)
Card remote commander RM-X122
Power requirements
CR2025 lithium battery
Operable range
Approx. 2.5 m (8.22 ft.)
Dimensions 52
Ч
125
Ч
10 mm
(2 1 /
8
Ч
5
Ч
13 /
32
in.)
(w/h/d)
Mass Approx. 40 g (1 oz)
(including batteries)
Supplied accessories
Connection box XA-113 (1)
Card remote commander RM-X122
(with supplied battery) (1)
Power supply cord (1)
DC-DC cord (3 m) (1)
Stereo Mini Plug-to-Plug cable (5 m) (1)
Monitor cable (5 m) (1)
Collar (1)
Screws (4)
Operating Instructions (1)
Optional accessories
DVD player DVX-11A, MV-101
Cordless headphones MDR-IF140
PS one™
Design and specifications are subject to
change without notice.
