LG US670H Pro:Centric 4K HDR SmLED Hospitality TV (43") - Manuel (Page 14)

6
ENGLISH
Optional Extras
Optional extras can be changed or modified for
quality improvement without any notification.
Contact your dealer for buying these items.
These devices work only with certain models.
The model name or design may be changed due to
the manufacturer’s circumstances or policies.
(Depending upon model)
Magic Remote Control
AN-MR18HA
Check whether your TV model supports Bluetooth in
the Wireless Module Specification to verify whether it
can be used with the Magic Remote.
Wall Mounting Bracket
Make sure to use screws and wall mounts that meet
the VESA standard. Standard dimensions for the wall
mount kits are described in the following table.
A
B
Model
43US670H0UA
50US670H0UA
49US770H0UA
43US670H9UA
50US670H9UA
55US670H0UA
55US770H0UA
55US670H9UA
VESA (A x B) 200 x 200 300 x 300
Standard screw M6 M6
Number of screws 4 4
Wall mount bracket
(optional)
LSW240B
MSW240 OLW480B
MSW240
Model 65US770H0UD 75US770H0UD
VESA (A x B) 300 x 300 600 x 400
Standard screw M6 M8
Number of screws 4 4
Wall mount bracket
(optional)
OLW480B LSW640B
Lifting and Moving the TV
When moving or lifting the TV, read the following to
prevent the TV from being scratched or damaged and
for safe transportation regardless of its type and size.
• It is recommended to move the TV in the box or
packing material that the TV originally came in.
• Before moving or lifting the TV, disconnect the
power cord and all cables.
• When holding the TV, the screen should face away
from you to avoid damage.
• Hold the top and bottom of the TV frame firmly.
Make sure not to hold the transparent part, speaker,
or speaker grille area.
• Use at least two people to move a large TV.
